Yoga mat cutting machine with blade
With the popularity of yoga, the market demand for yoga mats has increased significantly. The increase in yoga mat orders has prompted manufacturers to increase their demand for production machines. AOL yoga mat CNC cutting machines are welcomed by the flexible material industry with high precision and high quality cutting. The sexual cutting function is more suitable for the economic needs of enterprises.
Detailed introduction

Yoga mat material application

Material of Yoga mat

 TPE foam, PVC foam, EVA, latex cushion, CBR cushion

Thickness of Yoga mat

The thickness of the yoga mat is generally about 3-7mm, the thickness of the yoga mat of PVC material can reach 7mm, and the thickness of the yoga mat of TPE material can reach 10mm.

Yoga mat Area

 The international standard size is 183*61 (cm) and 173*61 (cm)


Advantage of  AOL Yoga mat CNC cutting machine

1. AOL CNC sysytem is equipped with professional industrial vision system, projection positioning, irregular contour recognition and other multi-function assistance.

2. AOL CNC system compatible with multi-format files supports one-key import to start cutting.

3. Unique tool changing system, choose cutting tool according to cutting material, not just cutting yoga mat material

4. Infrared anti-collision and anti-static dual safety system provide a safe operating environment.

5. The simple and easy-to-operate AOL CNC cutting system reduces technical operation requirements, and employees can quickly learn and start using it.

details of Yoga mat cutting machine

Parameter of AOL Yoga mat CNC cutting machine

Technical parameters / model AOL-1625 AOL-1825
Effective working area 1600x2500mm 1800x2500mm
Multi-function tool Pneumatic knife, projector,vibrating knife,Round knife
safety devices Using infrared sensors,  responsive, safe and reliable,Anti-collision system,Four corner emergency stop button
Cutting speed 300-2000mm/s
Cutting thickness ≤50mm Other thicknesses can be customized according to the material
Applicable materials Long-haired carpets, carpets, car floor mats, textile carpets, cotton and linen carpets, Particle fleece,Diatom mud carpet, fake wool carpet, printed carpet,etc.
Material fixing method Vacuum partition adsorption
Transmission port Network port
Transmission system The X\Y axis is divided into two kinds of rack or belt
rated power 11kw
Rated voltage 380V±10%/220V±10% Optional
Control System Chinese and English LCD touch screen
Operating environment Panasonic servo motor, high precision helical gear reducer, Taiwan Yintai rail, Germany Henryan rack, Omron sensor, Schneider low-voltage appliances, Taiwan Mingwei power supply, Germany cable, 42mm adsorption platform, automatic feeding, Taiwan rail, energy saving fan
Support file format AI、PLT、DXF、PDF、 PCE、XML
Overall size 3600*2400*1250 3600*2600*1250


AOL service

1) Three-year warranty policy, free inspection and maintenance of main components.

2) Provide lifetime free technology upgrade service

3) Wearable parts (such as blades, workbench covers) are always available at cost when needed.

4) Free operation training is conducted in our factory. If there is not enough time, we will send detailed training videos.

5) 24-hour online service, providing free technical support in different languages.

6) On-site technical support can be provided when needed.

Packing details of AOL Yoga mat CNC cutting machine

1. Full film packaging machine (to prevent moisture)

2. Anti-collision edging

3. Wooden box packaging (standard specifications)

4. A warning sign is posted on the packaging box

5. The packaging details can be negotiated amicably.

Packaging process

To learn more about the performance of the machine, click on the message and let the professionals reply.

contact us


AOL Media

Youtube:<<click to jump>>

Website:<<click to jump>>

Facebook:<<click to jump>


Machine Display
Control System
Independent research and development of human-machine interface operating system, humanized design, intelligent recognition of knife cutting, fast capture of cutting targets.
Accurate and Stable Working Table
The cutting table is build with aviation aluminum with honeycomb structure inside; sturdy, high-precision, stable for long-term running.
Imported Servo Motor
The machine with more stable performance and higher precision.
Modutarized Cutting Tools
The modularized design ensures the cutting tools can be used on all the AOL product series.
The Thickness
The thickness of machine some steel plate parts is 12-20mm, it ensures the machine will be non-deformation permanently.
Projection Positioning System
The user can also place the irregular material into the projection area for the alignment cutting, which greatly improves the utilization of the material.
Diverse Tools
Oscillating Knife Tool
The Electrical Oscillating Tool is super suitable for cutting the material of medium density.Coordinated with various kinds of blades, applied for cutting different materials.

Cutting materials: kt board , foam board, honeycomb board, car mat, seat cover, corrugated, cardboard, kt board, gray board, composite materials, leather, corrugated box.
Creasing Wheel Tool
A selection of creasing tools allows for perfect creasing on the corrugated materials. Coordinated with the cutting software,the tool can cut the corrugated material along its structure or the reverse direction to have a finest creasing result,without any damage to the corrugated material's surface.

Cutting materials: Packing box, folding card, corrugated Board, carton,etc.
V-CUT Knife Tool
Specialized for V-cut processing on corrugated materials,AOL v-Cut Tool can cut 0°,15°,22.5°,30°and 45°.

Cutting material: soft board , kt board , corrugated board, packing box, slotting of corrugated boxes, medium-density material v cuts, carton packaging, hard cardboard, gift boxes,etc.
Kiss-CUT Knife Tool
The kiss cut tool is mainly used for cutting vinyl materials (labels).aol cut makes it possible that the tool cuts through the top part of the material without any damage to the bottom part.It allows high cutting speed for material processing.

Cutting materials: sticker, car sticker, reflective materials, self-adhesive vinyl, label, vinyl, engineering reflective film, double-layer adhesives, etc.
Pneumatic Knife Tool
Driven by compressed air,Pneumatic Knife Tool with 6mm stroke, is especially for cutting hard and compact materials. Equipped with different kinds of blades,it can make different process effect.The tool can cut the material up to 110mm by using specialized blades.

Cutting materials: asbestos board, asbestos free board, PTFE, rubber board , fluorine rubber board, silica gel board, graphite board, graphite composite board, etc.
Milling Knife Tool
With imported spindle,it has a rotating speed of 60000 rpm.The router driven by high frequency motor can be applied for cutting hard materials with the maximum thickness of 22 mm.The customized cleaning device cleans up the production dust and debris.The air cooling system extends blade life.

Cutting materials: acrylic MDF board, pvc board, display stand, etc.
Drag Knife Tool
AOL drag knife tool can perfectly cut materials with the thickness up to 5mm. Compared to other cutting tools,it is the most cost-effective one that allows for the fastest cutting speed and lowest maintenance cost.

Cutting materials: backlit film, sticker, pp paper , folding card, flexible material less than 3mm thickness, advertising materials KT board, flexible plastics, mobile phone film, etc.
Driven Rotary Knife Tool
Driven Rotary Tool puts the materials by the high-speed rotating blades driven by the servo motor.The tool can be installed with circular blades and decagonal blades .etc which are especially suitable for cutting woven materials.

Cutting materials: textiles, canvas, leather, fabric, carbon fabric, glass fabric, carpet, blanket, fur, woven fabric, composite double, multi-layer material, flexible plastic, etc.
